Plastometers, resiliometers, and other apparatus used to evaluate rubber and rubber-like materials in the Naval Air Experimental Station's Physical Properties Laboratory. The instruments visible in the photograph are identified as follows (left to right): Williams Plastometer; Pusey and Jones Plastometer; Bashore Resiliometer; and T-50 Apparatus. This photograph was included in a 1949 Naval Air Experimental Station report on compounding rubber.
|Creator of work|
|Original file type||TIFF|
|Rights||Public Domain Mark 1.0|
|View in library catalog|
Naval Air Experimental Station, and United States. Navy. “Plastometers, Resiliometers, and Other Apparatus from the Naval Air Experimental Station,” circa 1949. Photographs from the Papers of J. Hartley Bowen, Box 1. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/3x816m647.
This citation is automatically generated and may contain errors.
