Engineers calendering experimental stocks of rubber

  • Circa 1949

Rights

Public Domain

Download selected image

Small JPG800 x 665px — 97.9 KBMedium JPG1200 x 997px — 186 KBLarge JPG2880 x 2392px — 767 KBFull-sized JPG4316 x 3585px — 1.4 MBOriginal fileTIFF — 4316 x 3585px — 44.3 MB
View
Public
Domain

View of two engineers, Stanley Bilker (background) and Ralph Harper (foreground), operating the calender sheeting machine at the the Naval Air Experimental Station's Rubber Compounding and Processing Laboratory. The calender was a National Rubber Machine 6" x 12" three-roll type used to process rubber into continuous sheets of a pre-determined gauge and to friction and coat fabrics. Roll temperatures ranged from 50 to 350 degrees Fahrenheit and were controlled manually by circulating water, steam, or a mixture of both. This photograph was included in a 1949 Naval Air Experimental Station report on compounding rubber.

Property Value
Creator of work
Format
Original file type TIFF
Genre
Extent
  • 8 in. H x 10 in. W
Subject
Rights Public Domain Mark 1.0
Credit line
  • Courtesy of Science History Institute

Physical location

Department
Collection
Physical container
  • Box 1
View in library catalog

Cite as

Naval Air Experimental Station, and United States. Navy. “Engineers Calendering Experimental Stocks of Rubber,” circa 1949. Photographs from the Papers of J. Hartley Bowen, Box 1. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/4x51hj023.
