Scientific apparatus and instruments, Electronics

Variable Capacitor

  • Undated

Rights

BY 4.0

Download selected image

PDFSmall JPG1200 x 983px — 76.3 KBLarge JPG2880 x 2360px — 332 KBFull-sized JPG5285 x 4330px — 1.1 MBOriginal fileTIFF — 5285 x 4330px — 65.5 MB
View
This work is licensed under a Creative Commons Attribution 4.0 International License.
PDF
Download PDF

Tall rectangular wooden base with black plastic instrument panel; instrument panel is attached to base via four metal screws, two on each side; two small black plastic knobs that adjust up and down as they are turned are on the top of instrument panel, one on each side; large black plastic dial with knob in center of panel; dial has a white meter on it ranging from 0-100.

Capacitors function as storage devices for the holding of excess electricity at high voltage.

Manufacturer
Place of manufacture
Format
Genre
Medium
Extent
  • 17.8 cm H x 15.2 cm W x 15.2 cm D
Inscription
  • (Bottom right of panel) "NOM. MAX. VALUE / 0005MF"
  • (Center top of panel) "LEEDS & NORTHRUP CO. / PHILADELPHIA / 128125 / MADE IN U.S.A."
Subject
Rights Creative Commons Attribution 4.0 International License
Credit line
  • Courtesy of Science History Institute
