Close-up view of an ion source and oscilloscope designed for use with the Bendix Time-of-Flight Mass Spectrometer. One of four component parts of a mass spectrometer, the ion source produces a beam of particles characteristic of the sample material for qualitative and quantitative analysis. An oscilloscope is a laboratory instrument commonly used to display and analyze the waveform of electronic signals, in effect drawing a graph of the instantaneous signal voltage as a function of time. The Time-of-Flight Mass Spectrometer (TOFMS) was the flagship analytical instrument of the Bendix Corporation.
|Creator of work|
|Original file type||TIFF|
|Rights||No Known Copyright|
|View in library catalog|
Bendix Corporation. “Ion Source and Oscilloscope for Bendix Mass Spectrometer,” 1970–1979. Photographs from the Bendix Time-of-Flight Mass Spectrometer Collection, Box 3. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/8k71nh78k.
This citation is automatically generated and may contain errors.
