Plate 97: Device for draining water from a marsh, pool, or foundation by river current

Part of Le diverse et artificiose machine del capitano Agostino Ramelli

1588

Mechanics: undershot waterwheel; horizontal crankshaft; force pump; horizontal working beam; crank and connecting rod.

Author	Ramelli, Agostino, 1531-approximately 1600
Place of publication	France--Paris
Format	Image
Original file type	TIFF
Genre	Engravings Rare books
Extent	38 cm H
Subject	Machinery Pumping machinery Reciprocating pumps Water-power
Rights	Public Domain Mark 1.0
Credit line	Courtesy of Science History Institute

Physical location

Department	Library
View in library catalog

Cite as

Ramelli, Agostino. “Plate 97: Device for Draining Water from a Marsh, Pool, or Foundation by River Current.” In Le Diverse Et Artificiose Machine Del Capitano Agostino Ramelli. Paris, France, 1588. https://digital.sciencehistory.org/works/9880vr14w.
