General view of a glass spinning cell used during the early stages of nylon production and research at the DuPont Experimental Station in Wilmington, Delaware. In this design, the nylon polymer was melted in the glass chamber visible at the center of the photograph, which allowed researchers to study bubbles in the melt resulting from the decomposition of the polymer. Per this process, nylon chips were fed into the funnel situated at the top of the apparatus and dropped into a lock-chamber, where the air was exhausted and replaced with pure nitrogen. The chips were then dropped onto a heated grid and passed through a gear pump, filter, and spinneret before the resulting fiber was finally wound onto the bobbin visible on the lower left-hand side.
|Original file type||TIFF|
|Rights||No Known Copyright|
|View in library catalog|
“Glass Spinning Cell at DuPont Experimental Station,” March 25, 1937. Joseph X. Labovsky Collection of Nylon Photographs and Ephemera, Box 2. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/h989r3246.
This citation is automatically generated and may contain errors.
