General view of the Dynamic Test Laboratory at the Naval Air Experimental Station showing forced vibration machines and other equipment used to test rubber articles produced at the Station under simulated service vibration and flexure conditions. Located on the ground floor, the laboratory boasted a specially-designed concrete floor isolated from the building's foundation by a layer of cork and sand. This photograph was included in a 1949 Naval Air Experimental Station report on compounding rubber.
|Creator of work|
|Original file type||TIFF|
|Rights||Public Domain Mark 1.0|
|View in library catalog|
Naval Air Experimental Station, and United States. Navy. “Dynamic Test Laboratory at the Naval Air Experimental Station,” circa 1949. Photographs from the Papers of J. Hartley Bowen, Box 1. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/js956f82z.
This citation is automatically generated and may contain errors.
