Diagram of Bendix Mass Spectrometer
- 1970s
Schematic diagram of a section of a Bendix Time-of-Flight Mass Spectrometer, with view of the shock tube, oscilloscope, and attachment for a Knudsen cell or direct inlet system. The diagram is captioned "versatility," presumably to emphasize the adaptability of the Bendix system. The Time-of-Flight Mass Spectrometer (TOFMS) was the flagship analytical instrument of the Bendix Corporation.
| Property | Value |
|---|---|
| Creator of work | |
| Format | |
| Genre | |
| Extent |
|
| Subject | |
| Rights | No Known Copyright |
| Credit line |
|
Institutional location
| Department | |
|---|---|
| Collection | |
| Physical container |
|
Related Items
Cite as
Bendix Corporation. “Diagram of Bendix Mass Spectrometer,” 1970–1979. Photographs from the Bendix Time-of-Flight Mass Spectrometer Collection, Box 2. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/pn89d695x.
