Close-up view of a portion of the ion source for a Bendix Corporation Mass Spectrometer. One of four component parts of a mass spectrometer, the ion source produces a beam of particles characteristic of the sample material for qualitative and quantitative analysis. Per notations accompanying the photograph, this apparatus was designed to hold a Model 102 Magnetic Electron Multiplier.
|Original file type||TIFF|
|View in library catalog|
Bendix Corporation. “Ion Source for Bendix Mass Spectrometer,” 1957. Photographs from the Bendix Time-of-Flight Mass Spectrometer Collection, Box 3. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/xk81jk95w.
