Two views of an ion source and Model 105-G3 Magnetic Electron Multiplier designed for use with the Bendix Corporation Time-of-Flight Mass Spectrometer. One of four component parts of a mass spectrometer, the ion source produces a beam of particles characteristic of the sample material for qualitative and quantitative analysis, while the magnetic electron multiplier is used to detect and amplify ion bunches or peaks.
|Original file type||TIFF|
|View in library catalog|
Bendix Corporation. “Ion Source and Model 105-G3 Magnetic Electron Multiplier,” 1959. Photographs from the Bendix Time-of-Flight Mass Spectrometer Collection, Box 3. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/xk81jk965.
