Cross-section shows inner system, which is identical to that used for the fountain on Plate 184. Syphon action in the descending, snake-shaped pipes starts the water-flow, and inner system relies on changes in air and water pressure to keep the water circulating.
Mechanics: slotted-head screw; fountain.
