Plate 53: Device for raising water from a river or low place by river current

Part of Le diverse et artificiose machine del capitano Agostino Ramelli

1588

Mechanics: undershot waterwheel; oscillating double-wing pump; double interrupted crown gears and lantern gear; spur gear and lantern; worm and worm gear.

Author	Ramelli, Agostino, 1531-approximately 1600
Place of publication	France--Paris
Format	Image
Original file type	TIFF
Genre	Engravings Rare books
Extent	38 cm H
Subject	Machinery Pumping machinery Reciprocating pumps Water-power
Rights	Public Domain Mark 1.0
