Unloading of tensile sheet from mold

  • Circa 1949

Rights

Public Domain

Download selected image

PDFSmall JPG1200 x 986px — 161 KBLarge JPG2880 x 2365px — 692 KBFull-sized JPG4282 x 3517px — 1.3 MBOriginal fileTIFF — 4282 x 3517px — 43.2 MB
View
Public
Domain
PDF
Download PDF

View of a worker removing a tensile sheet from a mold used in the hydraulic press at the Naval Air Experimental Station's Rubber Compounding and Processing Laboratory. The hydraulic press is a 200-ton capacity Williams-White Moline machine equipped with three 24" x 24" cored steam platens and pull-back pistons for rapid pressure release. At the laboratory, the hydraulic press was used to cure, i.e. toughen or harden, molded rubber articles. This photograph was included in a 1949 Naval Air Experimental Station report on compounding rubber.

Property Value
Creator of work
Format
Genre
Extent
  • 8 in. H x 10 in. W
Subject
Rights Public Domain Mark 1.0
Credit line
  • Courtesy of Science History Institute

Institutional location

Department
Collection

View collection guide View in library catalog

Related Items

Cite as

Naval Air Experimental Station, and United States. Navy. “Unloading of Tensile Sheet from Mold,” circa 1949. Photographs from the Papers of J. Hartley Bowen. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/2b88qc202.
