Plate 167: Screw-jack for bending or breaking the iron gratings protecting a city wall or canal

  • 1588

Rights

Public Domain

Download selected image

PDFSmall JPG1200 x 1662px — 507 KBLarge JPG2880 x 3988px — 3.0 MBFull-sized JPG6312 x 8740px — 12.3 MBOriginal fileTIFF — 6312 x 8740px — 158 MB
View
Public
Domain
PDF
Download PDF

Can be operated by a single person, easily and with little noise. The device depicted here is also illustrated on Plate 166.

Mechanics: hand crank; worm and worm gear; double toggle linkage.
