Scientific apparatus and instruments, Electronics

Weston Galvanometer

  • Undated

Rights

BY 4.0

Download selected image

PDFSmall JPG1200 x 1699px — 137 KBLarge JPG2880 x 4077px — 652 KBFull-sized JPG5223 x 7394px — 2.1 MBOriginal fileTIFF — 5223 x 7394px — 111 MB
View
This work is licensed under a Creative Commons Attribution 4.0 International License.
PDF
Download PDF

Rectangular wooden box; brown leather handle attached to top with metal fasteners; front has a steel lock screwed to it; lock is stamped with manufacturer; four hard black rubber feet on bottom; top attached with two brass hinges; black painted aluminium instrument panel with raised meter; meter has a glass window over measurement bar; metal plaque attached to meter identifying the manufacturer; on flat part of panel are two plastic knobs; around each knob is a piece of copper wire; typed instructions are included.

Galvanometers detect and measure small amounts of electrical current through the use of a magnetic needle or a coil in a magnetic field.

Manufacturer
Place of manufacture
Format
Genre
Medium
Extent
  • 18.1 cm H x 19.7 cm W x 26.7 cm D (With case closed)
Inscription
  • (On lock) "EAGLE LOCK CO / TERRYVILLE, CONN / U.S.A."
  • (Plaque) "WESTON / MODEL No / ADJUST FOR ZERO (around screw) / WESTON ELECTRICAL INSTRUMENT CORP. / NEWARK, N.J. U.S.A."
Subject
Rights Creative Commons Attribution 4.0 International License
Credit line
  • Courtesy of Science History Institute

Institutional location

Department

Related Items

Cite as

Science History Institute. Weston Galvanometer. Photograph, 2016. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/6h440s49d.
