Two views of an ion source and Model 301 Magnetic Electron Multiplier designed for use with the Bendix Corporation Time-of-Flight Mass Spectrometer. One of four component parts of a mass spectrometer, the ion source produces a beam of particles characteristic of the sample material for qualitative and quantitative analysis, while the magnetic electron multiplier is used to detect and amplify ion bunches or peaks. According to notations accompanying the photograph, the Model 301 Multiplier was part of the Ultraviolet series.
|Creator of work|
|Original file type||TIFF|
|Rights||No Known Copyright|
|View in library catalog|
Bendix Corporation. “Ion Source and Model 301 Magnetic Electron Multiplier,” 1958. Photographs from the Bendix Time-of-Flight Mass Spectrometer Collection, Box 3. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/th83kz93t.
This citation is automatically generated and may contain errors.
