Overhead view of the first drawing machine used at DuPont's Buffalo plant during the early stages of nylon production and research. In this technique, which generally was unsuccessful, undrawn yarn was pre-twisted by the bobbin visible on the far right and then cold drawn in two stages.
|Original file type||TIFF|
|Rights||No Known Copyright|
|View in library catalog|
“First Drawing Machine at DuPont Buffalo Plant,” circa 1936. Joseph X. Labovsky Collection of Nylon Photographs and Ephemera, Box 1. Science History Institute. Philadelphia. https://digital.sciencehistory.org/works/zs25x8517.
This citation is automatically generated and may contain errors.
