Plate 144: Bridge for crossing a city or fortress moat and scaling its wall
- 1588
Barrels of earth and debris can be thrown into the moat from under the front of the machine as a decoy to distract from the doubled-over bridge, which can be unfolded quickly and unexpectedly.
Mechanics: winch; hand crank; spur gear and lantern; worm and worm gear; lantern and rack.
| Property | Value |
|---|---|
| Author | |
| Place of publication | |
| Format | |
| Genre | |
| Extent |
|
| Subject | |
| Rights | Public Domain Mark 1.0 |
| Credit line |
|
Physical location
| Department | |
|---|---|
| View in library catalog | |
Related Items
Cite as
Ramelli, Agostino. “Plate 144: Bridge for Crossing a City or Fortress Moat and Scaling Its Wall.” In Le Diverse Et Artificiose Machine Del Capitano Agostino Ramelli. Paris, France, 1588. https://digital.sciencehistory.org/works/tx31qh855.
