The Compound Spectroscope

  • Fig. 52

  • Part of Spectrum Analysis in its Application to Terrestrial Substances, and the Physical Constitution of the Heavenly Bodies
  • 1872 (Published)

Rights

No Copyright Public Domain

Download selected image

Small JPG800 x 1011px — 162 KBMedium JPG1200 x 1517px — 393 KBLarge JPG2880 x 3641px — 2.0 MBFull-sized JPG4524 x 5720px — 4.5 MBOriginal fileTIFF — 4524 x 5720px — 74.1 MB
View
No Copyright Public
Domain

Illustration of a man looking through a spectroscope.
From the corresponding text: "Fig. 52, especially the three tubes directed to the prism at different angles, as in that constructed by Kirchhoff and Bunsen. The eye of the observer is placed in the axis of the telescope directed to that surface of the prism from which the light emerges in the form of the spectrum; the opposite surface of the prism receives through the slit and collimating lens the light emitted from the object to be examined; at the side of the observer is the tube carrying the illuminated scale, or the micrometer screw, so that the mark coinciding with any division of the scale may be placed on any line of the spectrum."

Property Value
Author
  • Schellen, Heinrich, 1818-1884
Engraver
  • Laplante, Charles
Place of publication
  • England--London
Format
  • Image
  • Text
Genre
  • Publications
Extent
  • 662 pages
Language
  • English
Subject
  • Prisms
  • Scientific apparatus and instruments
  • Scientific illustration
  • Spectroscope
  • Spectrum analysis
Rights Public Domain Mark 1.0
Credit line
  • Courtesy of Science History Institute

Physical location

Department
  • Library
Physical container
  • Page 127
View in library catalog

Learn More

Historical biography
Robert Bunsen and Gustav Kirchhoff

Related Items

  • Bausch & Lomb Spectroscope
  • Spectrum of sodium / Solar spectrum / Action of prism on simple rays
  • Viewing Objects through a Prism

Cite as

Schellen, Heinrich. “The Compound Spectroscope.” Spectrum Analysis in Its Application to Terrestrial Substances, and the Physical Constitution of the Heavenly Bodies. London, England, 1872. https://digital.sciencehistory.org/works/wm117p851.
